SPECIFICATIONS Space: 2.5mm (0.098'') pitch Pole: 2-15 Applicable wires：AWG#22-30 Voltage rating: 250V AC, DC Current rating: 3A AC, DC Withstanding voltage: 800V AC/minute Insulation resistance: 1000MΩ min. Temperature range: -25℃ to+85℃（Including temperature rise in applying electrical current） Applicable PC board thickness: 0.8mm-1.6mm (0.031''-0.063'') Contact resistance: Initial value/10mΩ max. After environmental testing/20mΩ max
